Model No : ADCA-ST
The ADCA-ST series steam to water shell and tube heat
exchangers are shorter and lighter than the alternative shell
and tube exchangers manufactured with smooth pipes. The
use of extruded low fin tubes, has the advantage that it can
improve the external surface and thermal performance.
Corrosion-resistant stainless steel low finned tube bundle
Straight tubes for easy cleaning.
Floating head at the end of the tube bundle, avoiding tube
stresses caused by thermal expansion and contraction.
OPTIONS : Vertical installation, see STV
USE : Steam, water, hot condensate
and other fluids compatible with
STH/S – Carbon steel shell
STH/SS – Complete st. steel
CONNECTIONS : Flanged or screwed, according to
EN 1092-1 or ANSI standards.
INSTALLATION: Floor, wall, hanging from the
Steam runs inside the tubes and
process water outside.
ORDER REQUIREMENTS: Steam pressure and temperature Inlet and outlet water temperature
Water mass flow or heat exchanged.
See inquiry sheet.
